Asus Prime Z370-A II
ATX Z370 board (2018) for Intel 8th/9th Gen with overclocking, dual M.2, USB 3.1 Gen2, Intel LAN, TB header, and triple PCIe x16 slots.
As an Amazon Associate, GixCore earns from qualifying purchases.
Product overview
Released in 2018, the Asus Prime Z370-A II is an ATX Intel Z370 motherboard for 8th- and 9th‑gen Core processors on LGA1151. On our scale it’s a high_end Z‑series board: it exists to deliver CPU overclocking and a balanced feature set without paying for ROG extras.
It provides four DDR4 slots (up to 64 GB), two M.2 sockets (one PCIe/SATA, one PCIe), six SATA 6 Gb/s, and three mechanical PCIe x16 slots with x16 or x8/x8 lane layouts. Connectivity includes Intel Gigabit LAN, USB 3.1 Gen2 Type‑A and Type‑C, DisplayPort/HDMI/DVI for iGPU output, and no onboard Wi‑Fi. Notable: via its Thunderbolt header and Hyper M.2 X16 support, you can add ASUS ThunderboltEX and run multiple NVMe SSDs on CPU lanes. Discontinuation status is not officially stated.
- overclocking
- expansion/multi-M.2
- high-speed memory
Product highlights
- Compatible with intel 8th & 9th generation core processors to maximize connectivity and speed with dual m.2, USB 3. 1 gen2, intel thunderbolt 3 support and intel octane memory compatibility
- 5 way optimization with auto tuning and fan expert 4 automatically tailors overclocking profiles to your unique build for maximum OC performance and dynamic system cooling
- Unmatched personalization with asus exclusive aura sync RGB lighting, additional rgb header and 3d printing mounts; Operating system: Windows 10, 64 bit
- Two patent pending safe slots feature an injection molding process that integrates metal framing for a stronger, firmly anchored pie slot built for heavyweight GPUS
- Industry leading 8 channel hd audio enhanced by asus exclusive relate s1220a featuring crystal sound 3 and driven by Japanese capacitors for warm, immersive sound
Specifications
- Socket
- LGA1151
- WiFi
- No
- Integrated Graphics
- Yes
- Compatible Memory
- DDR4
- USB
- 3.1
- Max Memory Size
- 64 GB
- ECC Support
- No
- Chipset
- Z370
- Max RAM speed
- 4000 MHz
- Form factor
- ATX
- RAM slots
- 4
- M.2 slots
- 2
- PCIe x16
- 3
- Processor Generation
- 8, 9
- Pci E
- 3.0
- M 2
- PCI-E, SATA
- Sata Slots
- 6
- Sata Speed
- 6 Gb/s
- Pci E Slots
- 3
- Tdp
- 50 W
- Nvme
- Yes
- Pci E X1
- 3
- Cpu Brand
- Intel
