ASRock Z390 Phantom Gaming 4
2018 ATX Z390 board for 8th/9th‑gen Intel; enables overclocking, dual M.2, 4‑DIMM DDR4 up to 64 GB, PCIe 3.0 x16/x4, GbE, USB 3.1; no onboard Wi‑Fi.
As an Amazon Associate, GixCore earns from qualifying purchases.
Product overview
ASRock’s Z390 Phantom Gaming 4 launched on October 5, 2018 as part of ASRock’s Intel Z390 lineup for 8th- and 9th-gen Core (Coffee Lake/Refresh) on LGA1151. It’s an ATX board built on Intel’s Z390 chipset.
Positioned as a high_end Z‑series option, it exists to unlock CPU overclocking and fuller expansion versus B/H chipsets. It’s well-suited to builds that want affordable overclocking, dual NVMe capability, and plenty of add‑in room: 4× DDR4 DIMMs (up to 64 GB), two M.2 (PCIe/NVMe and SATA) plus six SATA 6 Gb/s, and PCIe 3.0 slots including two x16 (x16 or x16/x4) and three x1. Gigabit LAN and USB 3.1 round out connectivity; there’s no onboard Wi‑Fi. Availability today is limited as this is a legacy LGA1151 platform.
- overclocking
- expansion/multi-M.2
- high-speed memory
Product highlights
- LGA1151 Supports 9th and 8th Generation Intel Core Processors
- Chipset: Intel Z390
- Memory: 4x DDR4 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 64GB
- Slots: 2x PCI-Express 3.0 x16 Slots (run single at x16 or dual at x16/x4), 3x PCI-Express 3.0 x1 Slots (Flexible PCIe)
- Multi-Graphics: Supports AMD Quad CrossFireX, CrossFireX Technology
Specifications
- Socket
- LGA1151
- WiFi
- No
- Integrated Graphics
- Yes
- Compatible Memory
- DDR4
- USB
- 3.1
- Max Memory Size
- 64 GB
- ECC Support
- No
- Chipset
- Z390
- Max RAM speed
- 4300 MHz
- Form factor
- ATX
- RAM slots
- 4
- M.2 slots
- 2
- PCIe x16
- 2
- Processor Generation
- 8, 9
- Pci E
- 3.0
- M 2
- PCIe & SATA
- Sata Slots
- 6
- Sata Speed
- 6 Gb/s
- Pci E Slots
- 2
- Tdp
- 50 W
- Nvme
- Yes
- Pci E X1
- 3
- Cpu Brand
- Intel
